wider carbon rims clincher for 700C bike 88mm bike

Build Your RIM RR88C02 road bike/cyclocross

All wheels are 100% customizable at Light Bicycle. If your preferred specs are not listed, feel free to contact us (sales@lightbicycle.com) with your special requirements described.

Global Shop

NA Shop

EU Shop

AU Shop

Ships worldwide. See what's on sale>>

Drain Hole This is a required option.

With Drain Holes

Center Channel Hole This is a required option.

No Access Holes

Version This is a required option.

Front Flyweight / Rear Standard

Weave This is a required option.

Braided UD

DEFAULT SETTINGS

RIMS

Matte, UD, hook, blank (no decal), 24h

Paintless, UD, blank (no decal), 28h, with access holes

Standard, paintless, hook, blank (no decal), 24h, with drain holes, without access holes

HUBS

DT Swiss 350 Straightpull Centerlock Shimano Road 11s 36t

12/100mm (F) & 12/142mm (R)

DT Swiss 350 Straightpull Centerlock Sram XD 18t

15/110mm (F) & 12/148mm (R) boost

DT Swiss 350 straightpull centerlock Shimano Road 11s 36t

12*100mm (F) & 12*142mm (R)

SPOKES & NIPPLES

Sapim CX Sprint-rear drive side / CX Ray-other sides

Sapim aluminum black external

Sapim CX Ray & Sapim aluminum black external

Sapim CX Sprint-rear drive side / CX Ray-other sides

Sapim aluminum black external

ACCESSORIES

2 valves & 1 spare 18t ratchet

2 valves & 2 adapters (centerlock to 6-bolt)

2 valves & 1 spare 18t ratchet

Note: the wheelset price includes the warehouse transfer cost ($80).

Piece Weight: g+/-

Subtotal: USD +

Lead time: typically ships in 2 days

ADD TO CART You missed some options.

We do not stock this item at the European warehouse. See what we stock currently.

You can order this product from our Global or North American warehouse.

Please fill out this form with your special requests if you want to customize it. We will get back to you in 24hrs via email.

Center Channel Hole This is a required option.

No Access Holes

DEFAULT SETTINGS

RIMS

Matte, UD, hook, blank (no decal), 24h, with drain holes

Paintless, UD, blank (no decal), 28h, with access holes

HUBS

DT Swiss 350 Straightpull Centerlock Shimano Road 11s 36t

12*100mm (F) & 12*142mm (R)

DT Swiss 350 Straightpull Centerlock Sram XD 18t

15/110mm (F) & 12/148mm (R) boost

SPOKES & NIPPLES

Sapim CX Sprint-rear drive side / CX Ray-other sides

Sapim aluminum black external

Sapim CX Ray & Sapim aluminum black external

ACCESSORIES

2 valves & 1 spare 18T ratchet

2 valves & 2 adapters (centerlock to 6-bolt)

Note: the wheelset price includes the warehouse transfer cost ($80).

Piece Weight: g+/-

Subtotal: USD + (discount price)

Lead time: typically ships in 3 business days

ADD TO CART You missed some options.

We do not stock this item at the Australian shop. See what's available.

You can order this product from our Global / NA shops.

Please fill out this form if you are looking for a custom wheelset.

We'll get back to you soon to study the customization requests via email.

Our apologies, we do not offer this item at the Global warehouse.

Please order from other warehouses. Feel free to contact us (sales@lightbicycle.com) if you want to customize. We’ll get back to you in 24hrs.

Our apologies, we do not stock this item at the North American warehouse. Check this link to see what items we stock, or send us an email to discuss.

Our Global warehouse can make any rim model and ship worldwide. Please fill out this form with your special requests if you want custom rims/wheelset. We will get back to you via email to discuss in 24hrs.

Shopping Style

Options Features	Quick Buy	Full Custom
Options Features	Inventory	Parts in stock (Assembled upon order)	Manufactured upon order
Customization	Least customizable	100% Customizable
Lead Time	≤ 3 days	4 weeks typically
Availability	Limited models	All models
Shipping	Worldwide	Worldwide

Quick Buy (In Stock)

Full Custom (Made to Order)

DEFAULT SETTINGS

Rims

Hook, matte, UD, with drain holes

Hook, matte, UD, with access holes, with drain holes

Standard, hook, paintless, UD, 5-year warranty, with access holes, with drain holes

Front Flyweight / Rear Standard, paintless, UD, 5-year warranty, no drain holes

Paintless, UD, 5-year warranty, no drain holes

Grooved graphene surface, hook, matte, UD, with access holes, with drain holes

Grooved graphene surface, hook, matte, UD, no access holes, with drain holes

Matte UD, 32H, Centered (Staggered)

Hubs

Hope Pro 4 Fatsno J-bend 6-bolt

15/150mm (F) & 12/197mm (R) Sram XD

Straightpull centerlock black 24H

12/100mm & 12/142mm

Shimano Road 11S

DT Swiss straightpull / Bitex j-bend, centerlock, 28H

J-bend, DT Swiss 6-bolt / Bitex centerlock, 32H

15/110mm boost & 12/148mm boost Sram XD

DT Swiss straightpull / Bitex j-bend, black, 20H front / 24H rear

100mm QR & 130mm QR Shimano Road 11S

Spokes

Sapim CX Ray black

Sapim D-Light

Accessories

No decals/valves/tape

No decals/valves/tape/pads

No decals/valves

Piece Weight: g+/-

Subtotal: USD +

Lead time:

ADD TO CART

PREVIOUS NEXT

RIM SPECS

Use road bike/cyclocross
Size 700c
Material full carbon Toray T700
Type clincher
Weight 690g+/-30
Tubeless ready
Spoke Hole 16H to 36H
Internal hole customized
ERD 464mm
Inner width 15.9mm
Outer width 23mm
Depth 88mm
Max weight limit 130kg
Max spoke tension 180kgf
Max tyre pressure 160psi
Finish matte/glossy
Decal customized
Weave UD/3K/12K
Warranty 15 Months
Standard En Standard

Rims

Our Pro series comes with a 5-year warranty (lifetime optional), while the non-pro with a 3-year warranty and crash replacement.)

Use: road bike/cyclocross
Size: 700c
Material: full carbon Toray T700
Type: clincher
Weight: 690g+/-30
Tubeless: ready
Spoke Hole: 16H to 36H
Internal hole: customized
ERD: 464mm
Inner width: 15.9mm
Outer width: 23mm
Depth: 88mm
Max weight limit: 130kg
Max spoke tension: 180kgf
Max tyre pressure: 160psi
Finish: matte/glossy
Decal: customized
Weave: UD/3K/12K
Warranty: 15 Months
Standard: En Standard

Full Custom

Get in touch with us (sales@lightbicycle.com) to discuss in detail your customization request.

Hole: Hole Count, Spacing, Pattern, Drilling Angle, Diameter
Finish: Matte, Glossy, Satin, Colored Paint
Weave: UD, 3K, 3K Twill (Vertical/Horizontal), 12K, 12K Twill (Vertical/Horizontal), Braided UD, Hexa-Comb
Brake Track: UD, 3K, 3K Twill (Vertical/Horizontal), 12K, 12K Twill (Vertical/Horizontal), Braided UD, Hexa-Comb
Weight Style: Standard, Flyweight, Ultra-Light, Heavy Duty, HD+

Explore more Full Custom services

Overview

88mm rims for bikes are with 23mm wide, it a trend in road and triathlon road bike wheels. they are becoming fat.There are many benefits for using wide rims for clincher wheels.
Specs
Rims

Use: road bike/cyclocross

Size: 700c

Material: full carbon Toray T700

Type: clincher

Weight: 690g+/-30

Tubeless: ready

Spoke Hole: 16H to 36H

Internal hole: customized

ERD: 464mm

Inner width: 15.9mm

Outer width: 23mm

Depth: 88mm

Max weight limit: 130kg

Max spoke tension: 180kgf

Max tyre pressure: 160psi

Finish: matte/glossy

Decal: customized

Weave: UD/3K/12K

Warranty: 15 Months

Standard: En Standard

Read more for actual road tire width

Full Custom

Get in touch with us (sales@lightbicycle.com) to discuss in detail your customization request.

Hole: Hole Count, Spacing, Pattern, Drilling Angle, Diameter

Finish: Matte, Glossy, Satin, Colored Paint

Weave: UD, 3K, 3K Twill (Vertical/Horizontal), 12K, 12K Twill (Vertical/Horizontal), Braided UD, Hexa-Comb

Brake Track: UD, 3K, 3K Twill (Vertical/Horizontal), 12K, 12K Twill (Vertical/Horizontal), Braided UD, Hexa-Comb

Weight Style: Standard, Flyweight, Ultra-Light, Heavy Duty, HD+

Explore more Full Custom services
Warranty

For Non-Pro Series Rims: From the date of purchase, 3-year Standard Warranty.

For Pro Series Rims: From the date of purchase, 5-year Pro Warranty as standard and an upgraded optional lifetime Premium Warranty with minimum charge.

Crash Replacement: It is applicable with the same period as the warranty time range that you purchased for the rims with 10% /25% discount for Non-Pro series /Pro series.
In The Box

Please carefully inspect your package when unboxing and get in touch with us immediately if the package is damaged or anything is missing.

Together we can make this planet better. Join our sustainability program to reduce paper waste with the use of digital manuals.

Download user guides >>

Gallery

Jaimie : had my first race and wheels went very well.

Australia

David : Kartrin - I've built up ten or twelve sets so far using your carbon rims for my customers here throughout the United States. Mountain bike rims, road bike rims, aero rims, clincher and tubulars. Two sets for the ironman athlete, using the 50mm front and the 88mm rear, makes a fantastic combination. Customers are happy. I'm happy that your rims are one of the best rims that I have laced up. Having been building wheels since 1970, they are wonderful! Keep up the quality control. You make an excellent product.

USA

View More Reviews >>

COMMENTS

Chad 2018/06/21

Can you please send me a picture and the specifications or details of your new 88mm U shaped rim. Also, will it be tubeless ready? Thanks, Chad

LightBicycle 2018/06/22

Hi Chad, Yes, the RRU88C02 is tubeless ready. You can find the specs and rim profile below (It's right under the rim options). You can use rim tape , sealant and tubeless tire. Then the rims/wheels will ride tubeless well. Thanks, Lightbicycle

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

Shayne 2016/11/01

I was wondering if you guys manufacture full disc wheels for TT bike? Thanks

Light-Bicycle 2016/11/01

Hello Shayne, Thanks for your inquiry. Currently, we only have the disc wheels without brake tracks as attached picture showed, not full disc wheels. Does that work for you? Thanks, Light-bicycle

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

Manny 2016/08/30

How long would it take to shipped to the U.S.?

Light-Bicycle 2016/08/31

Hello Manny, Thanks for your inquiry. Lead time: it takes 12 business days for rims manufacturing Delivery time: EMS delivery takes another 4-7 days to arrive We’d like to recommend our new U shape 88mm clincher rim. The rim is with special material and New high TG resin, it will provide better braking surface performance than basalt braking surface. Rim profile attached for reference. Thanks, Light-bicycle

Edmund 2016/09/05

Hi how much is the shipping for 01 rim to Singapore and how long it will take?

Light-Bicycle 2016/09/06

Hello Edmund, Thanks for your inquiry. Currently, we have new U shape 88mm rim. Rim profile attached for reference. It is with special material and New high TG resin, it will provide better braking surface performance than basalt braking surface. Is that works for you, please find our quotations as below. RRU88C02 (clincher): 650 /-20g, $195/pcs The shipping cost is $33.30 for one rim to Singapore by EMS, and it is $37.40 for two rims. You can save much shipping cost if order more rims. Lead time: around 12 business days for rims manufacturing Delivery time: EMS delivery takes another 4-6 days to arrive Thanks, Light-bicycle
