Build Your RIM RR24T02 road bike/cyclocross

All wheels are 100% customizable at Light Bicycle. If your preferred specs are not listed, feel free to contact us (sales@lightbicycle.com) with your special requirements described.


RIM SPECS

  • Use road bike/cyclocross
  • Size 700C
  • Material full carbon Toray T700
  • Type tubular
  • Weight 290g+/-10
  • Spoke Hole 16H to 36H
  • Internal hole customized
  • ERD 592mm
  • Outer width 23mm
  • Depth 24mm
  • Max weight limit 110kg
  • Max spoke tension 180kgf
  • Max tyre pressure 160psi
  • Finish matte/glossy
  • Decal customized
  • Weave UD/3K/12K
  • Warranty 15 Months
  • Standard En Standard

Read more for actual road tire width

TECH

WARRANTY

For Non-Pro Series Rims: From the date of purchase, 3-year Standard Warranty.

For Pro Series Rims: From the date of purchase, 5-year Pro Warranty as standard and an upgraded optional lifetime Premium Warranty with minimum charge.

Crash Replacement: It is applicable with the same period as the warranty time range that you purchased for the rims with 10% /25% discount for Non-Pro series /Pro series.

Be the first to review this product and help riders of your style choose the most suited.

Write a review now >>

If you've got a longer story to tell and a few pictures won't cut it, check out our storytelling feature and consider sharing your story!

COMMENTS

D

Dan 2017/04/05

Hello- What spoke counts would build a reliable wheelset using the 24mm deep/23mm wide rims? I weigh 165 lbs. Thanks!


LightBicycle 2017/04/06

Hello Dan, Thanks for your inquiry. You are not a large rider. For road wheels, rims in 20H/24H will work for you. Thanks, Lightbicycle


REPLY

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

B

Bobby 2016/10/24

Hi; I need 24mm deep tubular rim with 24 holes (RR24T02), for internal nipples. Is it available and how long would it take to manufacture and deliver to Canada? Thanks, Bobby


Light-Bicycle 2016/10/25

Hello Bobby, Thanks for your inquiry. We are able to manufacture the 24mm rim in 24H and with internal nipple hole. Please find attached picture, is that what you like? Thanks, Light-bicycle


REPLY

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

P

paolo 2016/01/12

hello im from Italy I need rims for cyclocross, these rims are fine . I need two pairs of wheels . How should I buy rims ? Quanro cost me ? thanks


Light-Bicycle 2016/01/15

Hello Paolo, Thanks for your inquiry. Did you mean you like 4pcs 29er rims for cyclocross use? If so, we’d like to recommend the 27mm wide 29er clincher rim which is tubeless compatible. Please find attached rim profile. Thanks, Lightbicycle


REPLY

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

L

Louis 2015/07/12

I would like to order 4 RRU35T02 25mm wide 35mm deep tubular rims without brake track for disc wheelset. Can you tell me if they are currently available, when they would ship, and the shipping cost to USA? Thank you.


Light-Bicycle 2015/07/13

ello Louis, Thanks for your inquiry. RRU35T02 (25mm wide U-shaped 35mm tubular rim): 370 /-15g, USD145/pcs Rims are without braking surface for disc wheels. Please find attached rim cross-section drawing. For rim weave, do you prefer 3k, 12k or UD? Matte or glossy? 24H/24H? Please find below link. http://www.flickr.com/photos/light-bicycle/sets/72157631432948364/detail/ Thanks, Light-bicycle


REPLY

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

B

Bill 2015/06/19

hi all, are these rims in 30mm Depth 23mm wide available? 35mm U-Shape 25mm wide is to much for me! and 38mm - 23mm wide also. thanks a lot from berlin germany, bill


Light-Bicycle 2015/06/23

Hello Bill, Thanks for your inquiry. Currently, we only have 23mm wide 38mm depth & 25mm wide 35mm depth tubular rims, no 30mm depth rim. The 25mm width rim is much wider and stronger. Most of our customers chose this new one, and it is with nice feedback. We are sure that you will like it. RRU35T02 (25mm wide U-shaped 35mm tubular rim): 370 /-15g, USD145/pcs RR38T02 (23mm wide 38mm clincher rim): 340 /-15g, USD133/pcs Please find attached rims cross-section drawings. For rim weave, do you prefer 3k, 12k or UD? Matte or glossy? 20H/24H? Please find below link. Thanks, Light-bicycle


REPLY

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

S

sebastian 2015/06/21

helllo from Slovenia do you shiping to slovenia?? i wanna know if its posibile to fit on this rims tabular 19mm??


Light-Bicycle 2015/06/23

Hello Sir, Thanks for your inquiry. Yes, we can ship our products to Slovenia. Don’t worry. We had some customers from Slovenia already. Sorry, do you mean that if the 24mm tubular rim can work with 19mm tires? Or you like the 19mm tubular rim? RR24T02 (23mm wide 24mm tubular rim): 320 /-15g, USD129/pcs Please find attached rim cross-section drawing. For rim weave, do you prefer 3k, 12k or UD? Matte or glossy? 20H/24H? Please find below link. http://www.flickr.com/photos/light-bicycle/sets/72157631432948364/detail/ Thanks, Light-bicycle


REPLY

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

J

Jamie 2015/04/14

Hi, Are these rims available for purchase? If so, what would be the cost of 1 rim, 18 hole in 3k gloss finish, shipped to Australia?


Light-Bicycle 2015/04/15

Hello Jamie, Thanks for your inquiry. Yes, the 24mm tubular rim is for sale. We also have new 25mm wide U-shaped 35mm tubular rim. It is much wider and stronger. Most of customers chose the new one. Would you like to have a try? RR24T02 (23mm wide 24mm tubular rim): 320 /-15g, USD129/pcs RRU35T02 (25mm wide U-shaped 35mm tubular rim): 360 /-15g, USD145/pcs Please find attached rims cross-section drawing. It is ok to do 18H & 3k glossy. Thanks, Light-bicycle


REPLY

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

J

Jordy 2014/04/18

Hello, Can i order these rims with 24/28 spoke holes without braketrack? (Disc brake) gloss UD carbon


Light-Bicycle 2014/04/19

Hello Jordy, Thanks for your inquiry. Currently, the 23mm wide 24mm depth tubular rim is not available here.it is with 20.8mm wide. But there is 23mm wide 38mm depth tubular rim. Please find the attached cross-section drawing of rim. Is it OK for you? It’s OK to manufacture the rims with UD glossy and 24H/28H(no braking track). Thanks, Light-bicycle


REPLY

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

M

michael 2014/03/27

Hi, just wondering if these are out of backorder. I notice that in February another customer asked when they will be available, do you have any updates? thx


Light-Bicycle 2014/03/28

Hello Michael, Thanks for your inquiry. Currently, the lead time of rim is around 15 business days. We already added a new product line but there will be a period of adjustment. The lead time would be around 8 business days since May. For the 23mm wide 24mm tubular rim, it’s still not available. But there is 20.8mm wide rim. Is it OK for you? Please find the attached cross-section drawing. Thanks, Light-bicycle


REPLY

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

A

Alain 2014/02/24

Hello, The 24mm carbon tubular rim width 23 mm it available now ? or how long ? can give a date? I want to buy a pair of 24mm carbon tubular rims 23 width-20/24 holes-Internal nipples-12K matt finish Best regards, Alain


Light-Bicycle 2014/02/26

Hello Alain, The wide 23mm wide 24mm tubular rim is not available. It's hard to tell the exact time of availability. But there are 23mm wide 20mm and 38mm depth tubular rims. Please find the attached cross-section drawings. Is it OK for you? Thanks, Light-bicycle


REPLY

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

D

Darren 2013/12/10

Hi there, Would these rims be suitable to build with disc brake hubs in 28 hole for cyclocross? Or what tubular rims in 23-25mm would you recommend for cyclocross disc wheelsets? And how much to ship to new zealand? Thanks


Light-Bicycle 2013/12/11

Hello Darren, Thanks for your inquiry. The 23mm wide rims are more suitable for the cyclocross. It’s OK to build wheelss with disc brake hubs(28H). Currently, the wide 24mm tubular rim is not available. But there are wide 20mm and 38mm depth tubular rims. Please find the attached cross-section drawings. Which rim do you prefer? For the rims, do you prefer UD, 3k or 12k? Matte or glossy? Do you still want the braking track on the rims? The delivery cost is USD68 for 2pcs rims to New Zealand. Thanks, Light-bicycle


REPLY

Please leave your name here.

E-mail is required for further contact.

Please enter a message.

H

Hin 2013/11/21

Is it possible to make this rim with 21 spoke holes?


Light-Bicycle 2013/11/23

Hello Hin, Thanks for your inquiry. Currently, the wide 24mm tubular rim is not available. There are wide 20mm depth &38mm tubular rims here. Please find the attached cross-section drawings. Is it OK for you? For the rims, do you prefer UD, 3K or 12k? Matte or glossy? The spoke holes are 21H(G3) for both front and rear rims? You want to build the wheels like the attached picture, right? http://www.flickr.com/photos/light-bicycle/sets/72157631432948364/detail/ If you’d like to order, I can create an invoice accordingly(Hong Kong). Thanks, Light-bicycle


REPLY

Please leave your name here.

E-mail is required for further contact.

Please enter a message.
